Gefen GF-HD48G-1MPO HDMI 2.1 Fiber Optical Extender

GF-HD48G1MPO – Overview

High-speed & long-distance HDMI 2.1 transmission by optical fiber!

• Features:

  • High-speed & long-distance transmission by optical fiber
  • Compatible with HDMI standard v2.1
  • Supports OM3 (or OM4) fiber with
  • 8 core MPO/MTP connectors
  • I2C Data and Hot Plug Detection signal is transmitted by optical fiber
  • CEC control, EDID, and HDCP 2.3 premium content protection
  • Support for static & dynamic HDR, allowing for extended dynamic range and wide color gamut support
  • Supports VRR (Variable Refresh Rate)
  • EMI & Safety: CE, FCC
  • Optical Source: VCSEL Laser
  • O/E Converter: PIN Photo Diode
  • Using Fiber: 8-core (or 12-core)
  • MPO/MTP fiber optical cable (OM3, 50/125 μm, Polarity type A)


• Specifications:

  • Signal Support: HDMI v2.1
  • Video Bandwidth: 48.0 Gbps
  • Tmds Clock: 5940 Mhz
  • Supporting Resolution: 8K/4K UHD (Up to 7680×4320)
  • Distance: Up to 100 meters (330ft)
  • Connector/Fiber: HDMI 19 Pin (male) / MPO/MTP
  • Audio Support: Up to 8 Channel PCM, DTS Master, DTS:X, Dolby TrueHD, Dolby Atmos
  • Power Consumption: 0.75W (typ) ~ 0.95W (typ)
  • Dimensions: 300 x 16 x 31mm (11.81 x 0.63 x 1.22in)
  • Temperature Range: Operating: -20°C ~ 70°C (-4°F ~ 158°F), Storage: 0°C ~ 50°C (32°F ~ 122°F)


• Item Includes:

  • 2x 5V/2A DC Power Supply (Interchangeable connectors: US, UK, AU, EU)
  • 1x Optical HDMI Fiber Extender Transmitter
  • 1x Optical HDMI Fiber Extender Receiver
  • 1x Quick-Start Guide


• GTIN:

  0888814007473
